ZBEM32G03RIF18GB 32GB EMMC

Zbit eMMC device consists of NAND flash and a built-in MMC controller. This product is a high performance
and quality embedded storage solution and compatible with JEDEC standard eMMC5.1 specification. Its strong
ECC engine significantly improves error correction enabling longer device lifetime and an increased ability to
handle higher raw bit error rate. The eMMC controller and software directly manage NAND flash, including ECC,
wear-leveling, bad block management, garbage collection and performance optimization, and manage interface
protocols. This architecture insulates any revision of NAND flash from the eMMC Host, makes the device easy to
integrate and accelerates time-to-market.

◼ eMMC 5.1 specification compatibility
－ Compatible to eMMC 4.41/4.51/5.0
◼ Bus mode
－ Data bus width: 1 bit (default), 4 bits, 8
bits
－ Data transfer rate: up to 310MB/s
(HS400)
－ Timing mode: SDR/DDR/HS200/HS400
－ I/F boot frequency: 0 ~ 52 MHz
－ I/F clock frequency: 0 ~ 200 MHz
◼ Operating voltage range
－ VCC: 2.7 ~ 3.6V
－ VCCQ: 1.7 ~ 1.95V or 2.7 ~ 3.6V
◼ Temperature
－ Operating temperature: -25 ~ 85℃
－ Storage temperature: -45 ~ 85℃
◼ Support feature
－ RPMB - Boot partition
－ Write protection
－ Erase, discard, trim, sanitize
－ HPI
－ Background operations
－ Device health report
－ Field firmware update (FFU)
－ Sleep / awake
－ Packed command
－ Support Hardware ECC engine
－ Support auto power save mode
－ Preventing from sudden-power-off
